belt-typle ore color sorter sorting machine for Potash feldspar
Features:
1. Linear CCD true color technology, color hd identification, high speed sorting identification finer;
2. Visible light full-color spectrum distribution, can free adjustment spectral region;
3. By selecting different specifications ramp, do not need to replace the light source, can be suitable for a variety of grains, industrial pellet and sheet materials such as the classification;
4. High-definition imaging technology, photo collection selected images, but to one thousand kinds of materials, one hundred thousand kinds of color to define color choose, truly achieve widely USES color to choose;
5. Each group can be more independence synchronization task, a variety of color optional, can be synchronized meet Gregory, unclick, variety of color separation at the same time;
6. Leading LED lighting application technology, have high luminous efficiency, long service life, fast response speed, strong anti-jamming stability;
7. Powerful software platform operation, and easy to understand, easy to operate;
8. For skin, breaking disc, mildew, different colors, germination of peanuts and with rubble and clods of peanuts can realize precise sorting.
Technical Parameter
| Model | HL300 | HL600 | HL1200 | HL1200-Ⅱ | SL42 |
| Capacity(t/h) | 1~3 | 2~5 | 4~10 | 6~12 | 8~15 |
| Voltage(V) | AC220V
50/60Hz | AC220V
50/60Hz | AC220V
50/60Hz | AC220V
50/60Hz | AC220V
50/60Hz |
| Power(KW) | ﹤0.8 | ﹤1.4 | ﹤2.4 | ﹤3.0 | ﹤5.5 |
| Air pressure(Mpa) | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
| Dimension(mm) | 3650*
1130*2110 | 3650*
1430*2110 | 3650*
1430*2110 | 3800*
1880*1650 | 3800* 2000*1650 |
| Weight (Kg) | 530 | 1000 | 1500 | 1500 | 2000 |
Sorting example
Packing & Delivery
Size: 3650*1430*2110mmmm
Weight:1000(±5%)kg
Packaging Details:The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Our Service
1. The company persists in the “Service is Available at Any Time” guidelines, advocates all staffs to pay close attention to the customer demands at any time,and endeavors to provide the solutions for the domestic and overseas customers.
2. At present, the company has more than 30 after-sales service staffs, who offer the service extending to the prefecture level, contact the customers directly,provide the timely, rapid and considerate service for the customers, and realize the door-to-door service within 72 hours.
3. Carry out one-year free maintenance and care of the complete machine for the customers, provide the professional training and technical guidance timely to solve the worries of the customers, and reflect the service mode of fast response, imely maintenance and tracking coordination fully.
